Product introduction：
8.4W series LED horizontal switching power supply with eight functions infrared remote control. It conforms to the PSE certification standard for switching power supply with overload protection, overvoltage protection, constant voltage function, constant current function, eight blinking functions and other options. And the products are divided into two types for indoor use and outdoor waterproofing according to the use environment. The products are mainly used in the field of LED lighting and LED decoration. Such as power supply for Christmas lighting, decoration power supply.
Specifications:
| Model | GP-SWXXXDCXXXX(JP)-1CT,IP20 SERIES GP-SWXXXDCXXXX-IP44(JP)-1CT,IP44 SERIES |
| Physical dimension | L x W x H : 101.5mmx 50mmx 56.5mm |
| Input voltage | 100-240V~ |
| Input frequency | 50-60Hz |
| Output voltage | 3-36VDC |
| Output Power | 8.5W Max |
| Special function | OCP,SCP |
| HIPOT Testing | 2000Vac/5mA/Min |
| AC pin type | JP |
| Mean time between failures | 50,000 HOURS AT FULL LOAD AND 25°C AMBIENT |
| Application | LED Driver |
| Safety certification | JET6372-61010-2001 JET6372-61010-2002 |
| Energy efficiency standards | VI |
| Protection index | IP20-IP44(Indoor/Outdoor use) |
| Burn-in | 100% Full Load Burn in |
| Operating temperature | -20~40℃ |
| Control mode | Infrared remote control |
| 8 functions | 1.COMB 2.IN WAVES 3.SEQUENTIAL 4.SLO-GLO 5.CHASING/FLASH 6.SLOW FADE 7.TWINKLE/FLASH 8.STEADY ON |
| Timing | Perform free setting for 0-24 hours |
| Dimming | Four Dimmer:100%、75%、50% 、25% |
